VIM-18
VACUUM INK MIXER
IM-06
INK MAX MACHINE
Model：
IM-06
Use to：
Ink stirring.
Characteristic：
1,Stable operation, digital display operation.
2,Ink can clamping fast, easy to operate.
|
1、Stirring Drive Mechanism |
|
|
Stirring Motor |
60W |
|
Stirring Speed |
0-130rpm |
|
Mixing Method |
The ink tank rotates (clockwise unidirectional operation), the stirring rod remains fixed |
|
Mixing Time |
0- 600min(It can also be set for unlimited continuous operation) |
|
2、Stirring Clamping Mechanism |
|
|
Mixing knife Material |
SUS304 |
|
Ink cartridge holder Material Platfom |
Aluminum alloy |
|
Ink collet clamping range |
1- 5KG φ90- φ180mm |
|
3、Power＆ Machine Appearance |
|
|
Power Supply |
220V、3PH、Rated Power：90W |
|
Body Material |
Baking paint |
|
Physical Dimension |
L330mm*W250mm*H750mm |
|
Machine Weight |
about 15KG |
|
Due to product updates, the product specifications in this catalog are subject to the latest physical products. |
|
